Yamaha RX-V1400

GENERAL

• Type

  AV receiver

• Manufacturer

  Yamaha

DISPLAY

• Display Dimmer

  Yes

AUDIO

• Amplifier Output Details

  110 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.04% - 2 channels (front)110 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.04% - 1 channels (center)110 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.04% - 2 channels (rear)110 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.04% - 1 channels (surround back)140 Watt - 8 Ohm - at 1 kHz - THD 0.7% - 2 channels (front)140 Watt - 8 Ohm - at 1 kHz - THD 0.7% - 1 channels (center)140 Watt - 8 Ohm - at 1 kHz - THD 0.7% - 2 channels (rear)140 Watt - 8 Ohm - at 1 kHz - THD 0.7% - 1 channels (surround back)

• Response Bandwidth

  10 - 100000 Hz

• Signal-To-Noise Ratio

  100 dB

• Total Harmonic Distortion

  0.04 %

AUDIO SYSTEM

• Type

  AV receiver

• Subcategory

  AV components

• Functions

  AV receiver

• Audio D/A Converter

  24bit / 192kHz

• Built-in Decoders

  DTS 96/24, DTS Neo:6, DTS decoder, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, Dolby Digital, Dolby Digital Surround EX, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx

• Surround Sound Effects

  CINEMA DSP, Virtual CINEMA DSP

• Surround System Class

  6.1 channel

• THX certified

  Yes

• Digital Sound Processor (DSP)

  Yes

• DSP Preset Qty

  31

• DSP Presets

  7ch stereo, Adventure, Rock Concert, Sci-Fi, Silent Cinema, Spectacle, Variety/Sports, Concert Hall, Disco, Enhanced, Game, General, Jazz club, Mono Movie, Music

• Additional Features

  A-B speaker switch, Midnight Mode, on-screen display

• Bass Control

  Yes

• Treble Control

  Yes

• Built-in Clock

  sleep timer

POWER DEVICE

• Power Consumption Operational

  500 Watt

• Power Outlets

  2 AC outlets

• Type

  power supply

HEADER

• Brand

  Yamaha

• Product Line

  Yamaha

• Model

  RX-V1400

• Packaged Quantity

  1

TUNER

• Response Bandwidth

  20 Hz

• Signal-To-Noise Ratio

  76 dB

• Total Harmonic Distortion

  mono: 0.2%, stereo: 0.3%

BUILT-IN DISPLAY

• Type

  fluorescent

MISCELLANEOUS

• Included Accessories

  AM antenna, microphone, FM antenna, universal remote control

• Timer

  sleep

EQUALIZER

• Equalizer

  Yes

• Equalizer Type

  parametric

• Equalizer Band Qty

  7 bands

AMPLIFIER

• Input Impedance

  47 Ohm

• Input Sensitivity

  200 mV

AMPLIFIER OUTPUT DETAILS

• Output Power / Channel

  110 Watt, 140 Watt

• Output Impedance / Channel

  8 Ohm

• Frequency Response

  20 - 20000 Hz, at 1 kHz

• Total Harmonic Distortion (THD)

  0.04 %, 0.7 %

• Channel Type

  center, front, rear, surround back

• Channel Qty

  1, 2

RADIO

• Tuner Type

  digital

• Tuner Bands

  AM/FM

• Tuning Display

  fluorescent display

• Preset Station Qty

  40

• Auto Preset Memory

  Yes

• Antenna Form Factor

  loop AM / wire FM

INPUTS & OUTPUTS

• Headphone Jack

  Yes

• Coaxial Digital Input

  Yes

• Optical Digital Input

  Yes

• Optical Digital Output

  Yes

REMOTE CONTROL

• Type

  universal remote control

• Remote Control Technology

  infrared

ACCESSORIES

• Supported Devices

  CD recorder, DVD player, TV, VCR

• Features

  LCD display, learning, multi-brand compatibility

AUDIO SPECIFICATIONS

• Type

  Amplifier, Radio tuner

• Frequency Response

  10 - 100000 Hz, 20 - 15000 Hz

• Signal-To-Noise Ratio

  100 dB, 76 dB

POWER

• Form Factor

  internal

• Power Consumption Stand by / Sleep

  0.5 Watt

• Power Outlets

  2 AC outlets

BATTERY / POWER

• Type

  power supply

CONNECTIONS

• Type

  5.1 channel audio line-in, 7.1 channel audio line-out, audio line-out, audio line-out (multi zone), component video input, component video output, composite video output, composite video/audio input, headphones, remote control, speakers output, S-Video input, speakers output (multi zone), turntable audio input, S-Video output, SPDIF input, SPDIF output, audio line-in

• Qty

  2, 6, 9, 3, 4

• Connector Type

  4 pin mini-DIN, RCA x 3, RCA x 6, RCA x 8, TOSLINK, banana/spade x 2, click-fit x 2, phone stereo 6.3 mm, RCA, RCA x 2

• Connector Location

  front, rear

AV FURNITURE

• Type

  none

DIMENSIONS & WEIGHT

• Depth

  17.1 in

• Width

  17.1 in

• Height

  6.7 in

• Weight

  34.17 lbs

GENERAL

• Manufacturer

  Yamaha
